Cache Titanium
40
700c
Complete bikes ship unassembled & require a full build. Spec is subject to change without notice. If you have any questions, contact us at info@knollybikes.com.
Titanium
Carbon fork
A new carbon adventure fork, with added tire clearance for 700*55c (650*2.4"), triple cage mounts for fenders and panniers, 398mm Axel to Crown and an adjustable offset of 47mm or 52mm.
Custom tubing
We feature custom tubing throughout this model so that the bike balances the perfect level of stiffness and comfort for any all mountain adventure. And each frame size features the appropriate tube diameter for that particular size, which allows us to tailor the stiffness from our smallest to largest sized frames.
Progressive Geometry
Utilizing our mountain bike expertise, we wanted to offer a bike that felt comfortable on both short and long-haul rides, as well as multi-surface terrains. We designed the Cache with a longer front center and a shorter stem to ensure it had optimal handling to expertly manage technical corners, while still being predictable, stable and comfortable on epic adventure rides.
Human Centric Sizing
We have always believed in human centric sizing and design our bikes to deliver optimal reach, standover height and geometry for a broad range of riders.
Sizing
| 49.5 | 152 - 157cm |
|---|---|
| 52 | 157 - 162cm |
| 54 | 165 - 170cm |
| 56 | 172 - 177cm |
| 58 | 180 - 185cm |
| 60 | 185 - 187cm |
| 62.5 | 190 - 195cm |
Geo
| 49.5cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62.5cm | |
|---|---|---|---|---|---|---|---|
| Effective Top Tube Length | 545.5 | 557.5 | 569.5 | 581.5 | 593.5 | 606 | 622 |
| Head Angle | 70.5º | 70.5º | 71º | 71º | 71º | 71º | 71º |
| Head Tube Length | 128 | 143 | 157 | 172 | 187 | 202 | 217 |
| Stand Over Height | 646 | 665.5 | 685.5 | 703 | 717 | 767.5 | 775 |
| Seat Tube Length | 410 | 438 | 464 | 492 | 520 | 548 | 576 |
| Seat Tube Angle | 74º | 74º | 74º | 74º | 74º | 74º | 74º |
| Wheelbase | 1022.5 | 1035.5 | 1043.5 | 1056.5 | 1069.5 | 1082.5 | 1100 |
| Stack | 558.5 | 572.7 | 588 | 602 | 616.5 | 630.5 | 644.5 |
| Reach | 385 | 393 | 401 | 409 | 417 | 425 | 438 |
Specs
| Seat Tube Angle | 72.5º |
|---|---|
| Effective Seat Tube Angle | 74º |
| Chainstay Length | 422mm |
| BB Height (40mm tire) | 276mm |
| BB drop | 75mm |
| BB size | 68mm threaded |
| Seat Post Diameter | 31.6mm |
| Fork AC Length | 402mm (397mm Fork + 5mm Headset) |
| Front Derailleur Mounting | Braze On Type |
| Rear Hub Spacing | 142 x 12mm |
| Tire Clearance | 700c x 45mm or 650b (27.5") x 2.1" |
| Headset | 44mm upper & 56mm lower (same as our MTN frames) |
Fork
| A/C Length | 398mm |
|---|---|
| Offset | 47mm / 52mm - Adjustable |
| Steerer | 1.5 Taper |
| Steerer Length | 300mm |
| Disc Brake | Flatmount w/ internal routing |
| Headset | 44mm upper & 56mm lower |
| Hub | 100 x 12mm Thru Axle |
| Tire Clearance | 700c x 55mm or 650b (27.5") x 2.4" |
| Weight | 465g with Thru Axle |
| Fender Mounts | M6 front of crown mounts and triple fender/rack/cage mounts |
Build Kits
Shimano GRX 600 1x |
Shimano GRX 600 2x |
|
|---|---|---|
| Fork | Carbon Adventure 700x55c / 650b x 2.4, Offset: 47mm / 52mm - Adjustable, triple fender/rack/cage mounts, M6 front of crown mount, internal dynamo routing, 398 axle to crown, 12x100mm | Carbon Adventure 700x55c / 650b x 2.4, Offset: 47mm / 52mm - Adjustable, triple fender/rack/cage mounts, M6 front of crown mount, internal dynamo routing, 398 axle to crown, 12x100mm |
| Headset | FSA Orbit ZS44/56 | FSA Orbit ZS44/56 |
| Stem | Easton EA50 AX 31.8 (60-80cm) | Easton EA50 AX 31.8 (60-80cm) |
| Handlebar | Easton EA50 AX 31.8 (42-46cm) | Easton EA50 AX 31.8 (42-46cm) |
| Grips | Easton Bar Tape Pinline Logo Black | Easton Bar Tape Pinline Logo Black |
| Brakes | Shimano GRX 600 | Shimano GRX 600 |
| Rotors | Shimano SM-RT70 160/160mm (Centerlock) | Shimano SM-RT70 160/160mm (Centerlock) |
| Shifter | Shimano GRX 600 Flat Mount Brakes | Shimano GRX 600 Flat Mount Brakes |
| Seat Post | RaceFace Ride XC 31.6x375mm | RaceFace Ride XC 31.6x375mm |
| Seat Collar | Knolly | Knolly |
| Saddle | SDG Duster P | SDG Duster P |
| Crankset | Shimano GRX 600 40T, 170mm | Shimano GRX 600 46-30T, 172.5mm |
| Bottom Bracket | Shimano 68mm BSA | Shimano 68mm BSA |
| Front Derailleur | n/a | Shimano GRX 810 2x11spd (Braze-On Front) |
| Rear Derailleur | Shimano GRX 812 1x11spd, Shadow Plus | Shimano GRX 810 2x11spd, Shadow Plus |
| Cassette | Shimano Deore M5100 11spd, 11-42T | Shimano 105 HG700 11spd, 11-34T |
| Chain | Shimano HG601 11spd | Shimano HG601 11spd |
| Wheelset | Shimano RS370 24h, 12x100 / 12x142 | Shimano RS370 24h, 12x100 / 12x142 |
| Front Tire | Maxxis Ravager EXO 700x40c | Maxxis Ravager EXO 700x40c |
| Rear Tire | Maxxis Rambler EXO 700x40c | Maxxis Rambler EXO 700x40c |
