Titanium
We use titanium because of its premium ride quality, anti-corrosion resistant characteristics and unlimited fatigue cycle. And our supplier is the best in the industry, enabling them to create the precise tooling required, so that they can produce the custom tubing we need for these models.
Carbon fork
A new carbon adventure fork, with added tire clearance for 700*55c (650*2.4"), triple cage mounts for fenders and panniers, 398mm Axel to Crown and an adjustable offset of 47mm or 52mm.
Custom tubing
We feature custom tubing throughout this model so that the bike balances the perfect level of stiffness and comfort for any all mountain adventure. And each frame size features the appropriate tube diameter for that particular size, which allows us to tailor the stiffness from our smallest to largest sized frames.
Progressive geometry
Utilizing our mountain bike expertise, we wanted to offer a bike that felt comfortable on both short and long-haul rides, as well as multi-surface terrains. We designed the Cache with a longer front center and a shorter stem to ensure it had optimal handling to expertly manage technical corners, while still being predictable, stable and comfortable on epic adventure rides.
Human Centric Sizing
We have always believed in human centric sizing and design our bikes to deliver optimal reach, standover height and geometry for a broad range of riders.
Design
Seat Tube Design
The Cache has a threaded BB shell, custom right side chainstay yoke, and full fender mounts. We worked with our factory to execute an industry first frame design that connects the down tube to the highly manipulated seat tube so that you can run an internal dropper post.
Utility
Compatibility
The Cache can be run as a traditional dual ring set up with a front derailleur or a single ring 1x system. Routing is provided for both mechanical and Di2 derailleurs and can be run internally or externally.
Design
Cable routing
The internal cable routing allows the housing to be run quickly and each end cap is designed to properly hold all the standard sized housing including Di2.
Drivetrain
Dropouts
Custom CNC'd dropouts combine the stiffness of the chainstay to the legendary flex of titanium in the seatstay. The offset tube position on the dropout hood also helps the frame absorb vibration before it gets to the rider.
Frame
Rear stays
The custom chain stays on this model are full of subtle features like a squared off top surface that is angled slightly outwards to improve the cable exit angle. The Cache also utilizes our mountain bike derailleur hanger so it is compatible with the Knolly already in your shed.
Frame
Cable Routing
Our cable routing features doors that are big for fast and easy installation, and the rubber ports can handle 4mm, 5mm and Di2 housing. This custom design keeps your housing from rattling in the frame.
