Fugitive | 125

$5,699.00 USD Sale Save

Our most popular 29er trail bike makes a comeback with a completely new tubeset, straight top tube design, & refreshed geo. It's equipped with Enduro bearings on all pivot locations & each frame size gets specific chainstays lengths and seat tube angles. The Fugitive is the most versatile model in our line-up & it's available in two suspension options that suits post-work backyard laps, weekend tech climbs, and mid-summer rocky descents.

Looking for MORE travel? Try the Fugitive 140.

  • REAR TRAVEL OPTIONS: 125
  • FORK OPTIONS: 140
  • WHEELS: 29"
  • STRAIGHT TOP TUBE: better standover and improved aesthetics
  • UNIFIED MONOBLOCK REAR LINK: works in collaboration with the lower swing link; increased rigidity and lessens lateral stresses on shock mount
  • ENDURO BEARINGS: in all pivots
  • FLAT TOOLING BEARING LOCATIONS: makes servicing bearings easier
  • SIZE SPECIFIC CHAINSTAY LENGHT: creates a better balanced bike and better fit for tall and short riders
  • SRAM UDH COMPATIBILITY: with Knolly specific fully CNC'd aluminum hanger included
  • SUPPORTS LONGER DROPPER POSTS: 200mm-240mm dependent on frame size for a wide range of inseam lengths
  • MOUNTS FOR TOOLS: under the top tube
  • LOWER SHOCK MOUNT: features 30mm axle to work with Fox Roller Bearing Shock hardware kits
  • POST MOUNT: direct 180mm rear brake mounts
  • 157TRAIL REAR END SPACING brings improved rear end stability and chainline

Complete bikes ship unassembled & require a full build. Spec is subject to change without notice. If you have any questions, contact us at info@knollybikes.com.

Sizing

S (S2)160cm - 170cm
M (S3)170cm - 180cm
L (S4)180cm - 190cm
XL (S5)190cm - 200cm

GEOMETRY

Fugitive 125

FRONT TRAVEL - 140mm / REAR TRAVEL - 125mm
NeutralSlack
Head angle66º65.25º
Effective seat tube angle77.25º76.5º
BB height334mm324mm
BB drop35mm45mm
S2 - SmallS3 - MediumS4 - LargeS5 - X-Large
Reach443mm470mm495mm520mm
Stack625mm625mm631mm640mm
Head tube length 108mm108mm115mm125mm
Effective Top Tube Length588mm615mm642mm669mm
Actual Top Tube Length587mm605mm627mm651mm
Seat tube length350mm390mm440mm490mm
Seat tube max insertion depth260mm300mm350mm400mm
Theoretical saddle height (from BB axis)700mm750mm800mm850mm
Seat tube angle (actual)68º68.5º69.25º71º
Stand over height701mm716mm726mm748mm
Chainstay length430mm434mm438mm442mm
Wheelbase length1184mm1215mm1247mm1280mm
Wheelbase Length BB Drop BB Height Reach Stack Chainstay Length Stand Over Height Effective Seat Tube Angle Seat Tube Angle (Actual) Head Angle Head Tube Length Seat Tube Length Effective Top Tube Length Actual Top Tube Length Theoretical Saddle Height (From BB Axis) Seat tube Max Insertion Depth

Specs

Fork A/C length554mm (140mm inc. headset)
Front travel140mm Nominal. Intended use: 140-150mm
Rear travel125mm
Wheel size and max width29" x 2.6"
Dropout/Hub spec12 x 157mm
Shock hardwareM8x30mm lower
Seat post diameter31.6mm
Seat post inner depth300mm+
Dropper post rangeSize XS: 175mm-200mm drop; Size Small, Medium & Large: 200mm+ drop
Headset44mm upper & 56mm lower
Post collar35mm
Frame material6066 Aluminum, Custom Titanium Hardware
Cable routingInternal with Di2 battery compartment
Chainguide mountISCG05
BB shell spec73mm / threaded
Chainline54-57 with 55-56.5mm optimal
Rear brake tabsPost mount 180mm
Geo settingsSlack or Neutral
Bottle mountsYes
Tool mountsYes

Build kits

XT
ForkFox 34 Factory Grip2 29" 140mm, 51mm Offset
ShockFox Float X Factory 185x50
HeadsetFSA Orbit ZS44/56
StemRaceFace Aeffect R 35mm x 50mm
HandlebarSpank 35mm x 800mm, 25mm Rise
GripsSpank Spoon
BrakeShimano XT 4 Piston M8120
RotorsShimano XT 203mm / 180mm (6-Bolt) SM-RT76
ShifterShimano XT 12spd M8100 (I-Spec EV)
Seat postSDG Tellis (S: 170mm, M-XL 200mm), 31.6
Seat collarKnolly
SaddleSDG Bel-Air V3
CranksetShimano XT M8130 30T, 170mm
Bottom bracketShimano XT MT800 BSA, threaded
DerailleurShimano XT M8100 12spd, Shadow Plus
CassetteShimano XT M8100 12spd, 10-51T, Hyperglide+
ChainShimano XT M8100
WheelsetSpank 359 HEX J-Bend 32h (MS)
Front tireMaxxis DHF 29" 2.5" 3C Maxx Terra EXO
Rear tireMaxxis DHR2 29" 2.3" 3C Maxx Terra EXO
