The Chilcotin 167 has more front and rear suspension so that you can take bigger hits, steeper lines and push the limits of your riding. It will roll fast and plow through the gnar with ease.
Chilcotin 167
Chilcotin 167
Chilcotin 167

Chilcotin 167

  • 170
  • 167
  • 29

SHIPPING NOW.

Please keep in mind that global shipping is still very unpredictable. It may take 5-10 business days for your order to be processed.

If you have any questions, contact us - info@knollybikes.com.

Bikes ship unassembled. Spec is subject to change due to supply chain challenges.
Please note: All orders are processed in USD.
$6,299.99
Color Blue

Only left in stock

Our patented Fourby4 suspension is designed to maximize rear shock performance and available traction in every situation, no matter how crazy things get. It reduces brake “squat” and enables your wheel to maintain contact with the ground to maximize your speed through the most challenging terrain. And our legendary pedalling traction ensures performance - even in the jank - so you can get on the gas when you need to eliminate another second off your time.

Learn more

157Trail

We feature 157Trail rear hub spacing which uses the wide flange 157 hubs with 73mm BB shells. This spacing provides the most options for tire size and can easily clear tire widths up to 2.6. With 157Trail, heel clearance is exceptional and chainring clearance remains huge at 36T.

Learn more

OSD

Our patented offset straight seat tube design (OSD) allows our riders to transition effectively between a highly efficient pedaling position and the “attack position” required for aggressive riding. It enables the rider to drop the saddle on the downs and is critical in allowing maximum rear wheel travel while keeping the back wheel away from the seat tube under full compression. This design allows us to run 200+mm dropper posts because our seat tubes are straight and un-interrupted.

Learn more

Human centric sizing

We have always believed in human centric sizing and design our bikes to deliver optimal reach, standover height and geometry for a broad range of riders.

Learn more

Sizing

S 155cm - 170cm
M 170cm - 178cm
L 178cm - 188cm
XL 188cm - 195cm

Geo



Medium Large X-Large
Head Tube Length 98 106 110
Stand Over Height 710 750 790
Seat Tube Length 405 456 503
Effective Top Tube Length 632 660 688
Wheelbase Length 1234 1263 1291
Stack 626 633 637
Reach 464 490 516



Slack Neutral
Head Angle 63.8º 64.5 º
BB Height 338 347
Effective Seat Tube Angle 76.9º 77.6º
Chainstay Length 438 436.5

Specs



Fork length (incl headset) 586mm
Front Travel 170mm
Rear Travel 167mm
Wheel size and max width 29" x 2.6"
Dropout/Hub Spec 12 x 157mm
Seat post diameter 31.6mm
Seat post insert depth 300mm+
Dropper post range Size Medium: 175mm drop; Size Large and XL 175mm - 200+mm drop
Head set 44mm upper & 56mm lower
Post collar 35mm
Frame material 6066 Aluminum, Custom Titanium Hardware
Internal cable routing with Di2 battery compartment Yes
Upper chain guide mount E-type direct mount (removable)
Chainguide Tabs ISCG05 (removable)
BB Shell Spec 73mm / threaded
Chainline 55-57 with 56.5mm optimal
Rear Brake Tabs Post mount 160mm
Two Geo settings Slack or Neutral
Bottle mounts Yes

Build Kits



GX

XT

Fork,167 kit RockShox ZEB 29" Ultimate RC2 170mm, 42mm offset Fox Float 38 29" Grip2 Factory 170mm, 44mm offset
Headset FSA Orbit ZS44/56 FSA Orbit ZS44/56
Stem Spank 35mm x 40mm RaceFace Aeffect R 35mm x 50mm
Handlebar Spank 35mm x 800mm, 25mm Rise RaceFace Next R 35mm x 800mm, 20mm Rise
Grips Spank / SDG Chromag Basis Black
Brake Magura MT5 Shimano XT 4 Piston M8120
Rotors Magura Storm HC 203mm / 180mm Shimano XT 203mm / 180mm (6-Bolt) SM-RT76
Shifter SRAM GX Eagle Lunar Shimano XT 12spd M8100 (I-Spec EV)
Seat Post SDG Tellis 170mm, 31.6 SDG Tellis 170mm, 31.6
Seat Collar Knolly bolt on Knolly
Saddle SDG Bel-Air V3 Chromag Lynx DT
Crankset SRAM GX Eagle 170 32T Ring Shimano XT M8130 30T, 170mm
Bottom Bracket SRAM Dub SB+ BSA, threaded Shimano XT MT800 BSA, threaded
Derailleur SRAM GX Eagle Lunar, 12 spd Shimano XT M8100 12spd, Shadow Plus
Cassette SRAM XG1275 Eagle 10-52T Shimano XT M8100 12spd, 10-51T, Hyperglide+
Chain SRAM GX Eagle Shimano XT M8100
Wheelset Spank Oozy Trail 345 HEX 32h J-Bend, 29" 15x110 / 12x157 Spank Oozy Trail 345 HEX 32h J-Bend, 29" 15x110 / 12x157
Front Tire Maxxis Assegai 29" 2.5WT 3C MaxxGrip EXO+ Maxxis Assegai 29" 2.5WT 3C MaxxGrip EXO+
Rear Tire Maxxis DHR2 29" 2.4" 3C MaxxTerra EXO+ Maxxis DHR2 29" 2.4" 3C MaxxTerra EXO+
